Brand: SY CHEMICAL
Models:16/25/38/50mm
Material: 304,304 L, 410,316,316 L
Application:It is suitable for various reaction towers, absorption towers and distillation towers, and is used for gas absorption, liquid separation and other processes.
A:Please send us your product specifications, quantity, and application details. Our sales team will provide a prompt quotation and professional recommendation based on your requirements.
A:We use standard export packaging to ensure safe transportation. Packaging methods can be customized according to product type and customer requirements to protect the goods during shipment.
Improve efficiency: Optimized design can significantly improve mass and heat transfer efficiency, bringing remarkable improvements to your production processes.
Economic benefits: Long service life means savings on frequent replacement and maintenance costs of refill material, resulting in lower overall operating costs.
Environmentally Friendly: The corrosion resistance of 316 stainless steel reduces material leakage caused by corrosion, making it more environmentally friendly.
| Size
(Inch/mm) |
Bulk density
(304,kg/m3) |
Number
(per m3) |
Surface area
(m2/m3) |
Free volume
(%) |
Dry Packing Factor m-1 |
|
| 1/4” | 6*6*0.3 | 900 | 4000000 | 904 | 88.6 | 1307.4 |
| 3/8” | 10*10*0.3 | 480 | 768000 | 482 | 93.8 | 583.8 |
| 1/2” | 13*13*0.3 | 420 | 410000 | 415 | 4.8 | 489.2 |
| 5/8” | 16*16*0.3 | 348 | 201000 | 344 | 95.5 | 393.2 |
| 1” | 25*25*0.4 | 288 | 53500 | 212 | 96.2 | 229.8 |
| 1” | 25*25*0.5 | 367 | 53500 | 216 | 95 | 237.2 |
| 1” | 25*25*0.6 | 439 | 53500 | 219 | 94.2 | 244.1 |
| 1.5” | 38*38*0.4 | 193 | 15180 | 143 | 97.2 | 148.4 |
| 1.5” | 38*38*0.5 | 246 | 15180 | 145 | 96.7 | 151.7 |
| 1.5” | 38*38*0.6 | 328 | 15000 | 146 | 95.9 | 154.6 |
| 2” | 50*50*0.5 | 185 | 6500 | 106 | 97.5 | 128.5 |
| 2” | 50*50*0.8 | 315 | 6500 | 108 | 96.8 | 130.5 |
| 2” | 50*50*1.0 | 380 | 6500 | 132.5 | 96.0 | 134.0 |
| 3” | 76*76*1.0 | 265 | 1920 | 69 | 97.4 | 79.6 |
| 3.5” | 89*89*1.0 | 224 | 1220 | 61 | 97.1 | 66.2 |
Industrial wastewater treatment: Faced with the complex composition of wastewater in the chemical and pharmaceutical industries, 316 stainless steel Pall rings provide a reliable solution that can effectively remove various pollutants.
Municipal Wastewater Treatment: Applicable to municipal water treatment facilities, where it helps reduce pollutants and improve water quality.
Biological Filtration Systems: widely used in biofilm treatment processes, the design and materials of Pall rings can provide the optimal biological carrier environment, promote the growth and reproduction of microorganisms, and improve purification efficiency.
316 stainless steel Pall rings are a key industrial packing material, particularly widely used in wastewater treatment. Made of high-quality 316 stainless steel, these Pall rings perform exceptionally well in harsh environments, exhibiting superior corrosion resistance, high-temperature resistance, and mechanical strength, making them ideal for use in a variety of complex chemical environments.
